Name: JZP-6.0B-SC Hot Product 2024 Rubber Shock Absorber with 6.7KG Load Range and Condition Monitoring
Brand: Xi'an Hoan Microwave Co., Ltd.
SKU: JZP-6.0B-SC, el cual es un avión de combate.
Availability: InStock

En casa > productos > amortiguador de choque de goma >

JZP-6.0B-SC Hot Product 2024 Rubber Shock Absorber with 6.7KG Load Range and Condition Monitoring

Hot Product 2024 Rubber Shock Absorber

6.7KG Load Range Vibration Isolator

Condition Monitoring Friction Damping Isolator

Lugar de origen:

Porcelana

Nombre de la marca:

Hoan

Número de modelo:

JZP-6.0B-SC, el cual es un avión de combate.

Contacta con nosotros

Solicitar una cita

JZP-6.0B-SC Hot Product 2024 Rubber Shock Absorber with 6.7KG Load Range and Condition Monitoring

Detalles del producto

Frecuencia de aislamiento:

5Hz

Durabilidad:

Alto

Rango de temperatura:

Ancho

Uso:

Absorber golpes y vibraciones.

Color:

Negro

Certificación de productos:

ISO 9001

Rango de carga:

6,7KG

Appliocation:

Autos, maquinaria, motores

Palabras clave de productos:

Dispositivos para el aislamiento de la fricción

Tipo de instalación:

Horizontal/vertical

Costo:

Asequible

Tipo de comercialización:

Producto caliente 2024

Frecuencia de resonancia:

30 HERZIOS

Ubicación de la sala de exposición:

Ninguno

Resaltar:

Hot Product 2024 Rubber Shock Absorber

6.7KG Load Range Vibration Isolator

Condition Monitoring Friction Damping Isolator

Condiciones de pago y envío

Cantidad de orden mínima

Condiciones de pago

LC, D/A, D/P, T/T, Western Union, MoneyGram

Productos relacionados

JZP-5.5B-SC Rubber Shock Absorber with Vibration Frequency 5-50Hz and Max Static Load 5.5Kg in 3-24 Inches Length

Obtenga el mejor precio

JZP-5.0B-SC Rubber Shock Absorber with 10Hz to 100Hz Frequency Range High Vibration Resistance for On-Vehicle Efficiency Validation New Product 2025

Obtenga el mejor precio

JZP-4.0B-SC Rubber Shock Absorber with M5 Mounting Holes 30mm Height and High Pressure Resistance for Vibration Isolation

Obtenga el mejor precio

JZP-3.5B-SC Modular Rubber Shock Absorber with 5-6KG Load Range 1:2 Compression Ratio and 40g/11ms Shock Resistance

Obtenga el mejor precio

Contacta con nosotros

86-29-88292913

Contacta ahora

Descripción del producto

JZP-6.0B-SC High-Performance Vibration Isolation and Condition Monitoring for Rubber Shock Absorber

JZP-B-SC Series

Towards the Future: Development Prospect of the JZP Series and Intelligent Vibration Isolation Technology

Technology knows no bounds. Xi'an Hoan Microwave Co., Ltd. continues to invest heavily in R&D, focusing on emerging demands for future on-vehicle vibration isolation technology. The JZP Series platform is evolving towards smarter, more integrated, and more active solutions.

Intelligent Vibration Isolation and Condition Monitoring

Future generations of the JZP Series may integrate micro MEMS accelerometers and IoT modules, enabling real-time monitoring of vibration isolation status and equipment vibration magnitude. This data can be uploaded to cloud platforms via wireless networks, supporting predictive maintenance, fleet management optimization, and vehicle Prognostics and Health Management (PHM).

Active and Semi-Active Vibration Isolation Technologies

For ultra-high vibration isolation requirements—such as on-vehicle lithography machines and quantum communication devices—Xi'an Hoan is exploring active/semi-active vibration isolation technologies. Using sensors, controllers, and actuators, this system can achieve precise control over specific frequency vibrations, especially low-frequency ones.

Dimension Parameter Table

Model	D (mm)	H±1 (mm)	h (mm)	A±0.2 (mm)	B (mm)	d	d2	R	B (mm)
JZP-B-SC	46	30	21	40	50	M4	∅5.5	5	22

Technical Parameter Table

Model	Nominal Load (kg)	Static Displacement (mm)	Working Temperature (℃)	Resonance Frequency (Hz)	Impact Test	Valid Period (year)
JZP-1.0B-SC	1.0	≤0.3	-45～+65	41.5±5	100G12times	8
JZP-1.5B-SC	1.5
JZP-2.0B-SC	2.0
JZP-2.5B-SC	2.5
JZP-3.0B-SC	3.0
JZP-3.5B-SC	3.5
JZP-4.0B-SC	4.0
JZP-5.0B-SC	5.0
JZP-5.5B-SC	5.5
JZP-6.0B-SC	6.0

Vibration and Impact Curve of JZP-B-SC Series

Vibration

Impact
