Name: JMZ-T1-2.0 Spring Isolator with 1 Year Warranty for Industrial and Commercial Applications and High Shock Absorption
Brand: Xi'an Hoan Microwave Co., Ltd.
SKU: JMZ-T1-2.0
Availability: InStock

En casa > productos > El aislante de resorte >

JMZ-T1-2.0 Spring Isolator with 1 Year Warranty for Industrial and Commercial Applications and High Shock Absorption

1 Year Warranty Spring Isolator

Industrial and Commercial Application Vibration Isolator

High Shock Absorption Friction Damping Isolator

Lugar de origen:

PORCELANA

Nombre de la marca:

Hoan

Número de modelo:

JMZ-T1-2.0

Contacta con nosotros

Solicitar una cita

JMZ-T1-2.0 Spring Isolator with 1 Year Warranty for Industrial and Commercial Applications and High Shock Absorption

Detalles del producto

Compatibilidad:

Se adapta a la mayoría de los equipos estándar

Estilo de diseño:

Industrial

Solicitud:

Industrial y comercial

Componentes centrales:

Cojinete

Mantenimiento:

Bajo mantenimiento

Tipo de montaje:

Atornillado

Absorción de choque:

Alto

Reducción de ruido:

Sí

Características:

Duradero y fácil de instalar

Garantía:

1 año

Color:

Plata

Disponibilidad:

Ampliamente disponible

Resaltar:

1 Year Warranty Spring Isolator

Industrial and Commercial Application Vibration Isolator

High Shock Absorption Friction Damping Isolator

Condiciones de pago y envío

Cantidad de orden mínima

Condiciones de pago

L/C, D/A, D/P, T/T, Western Union, Moneygram

Productos relacionados

JMZ-T1-1.4 32mm Overall Width Spring Isolator with 1 Year Warranty and High Resilience for Industrial Vibration Isolation

Obtenga el mejor precio

JMZ-T1-1.2 Spring Isolator with 95% Isolation Efficiency 32mm Overall Width and UL Listed for Vibration Isolation

Obtenga el mejor precio

JMZ-T1-0.6 Spring Isolator with High Resilience and Strong Shock Resistance for Durable Vibration Control

Obtenga el mejor precio

JMZ-T1-0.45 Friction Damping Vibration Isolator with Up to 95% Isolation Efficiency for 0-150°F Operating Temperature and 1 Year Warranty

Obtenga el mejor precio

Contacta con nosotros

86-29-88292913

Contacta ahora

Descripción del producto

JMZ-T1-2.0 The Ultimate Solution for Equipment Stability and Performance with Spring Isolator

JMZ-T1 Series

Redefining Stability Boundaries: The JMZ-T Series transforms equipment performance foundations into strategic advantages by addressing the critical relationship between installation stability and ultimate accuracy.

In precision engineering, vibration acts as a "precision assassin" originating from both external sources (ground fluctuations, human movement) and internal equipment components. The JMZ-T Series friction damping vibration isolators from Xi'an Hoan Microwave Co., Ltd. go beyond traditional vibration reduction to redefine equipment stability boundaries, converting basic vibration isolation into a core strategic performance advantage.

Unlike traditional solutions (rubber pads or ordinary springs) that may trigger resonance or cause prolonged oscillation, the JMZ-T Series implements proactive "energy management" through:

Innovative multi-stage friction damping mechanism
Precisely controlled internal friction pairs
Efficient conversion of mechanical energy to thermal energy
Rapid stabilization for improved performance

This technology delivers measurable benefits for precision measuring instruments (faster reading stabilization, higher data repeatability) and high-end manufacturing equipment (superior processing consistency, lower scrap rates).

The JMZ-T Series represents a paradigm shift - not just a component, but a "performance amplifier" that unlocks equipment design potential by creating an ideal static working platform.

Structural Dimension Diagram

Technical Parameters

Model	Max PZ-Direction Load	PZ Displacement Under Max Load	H (mm)	h (mm)	d (mm)	Weight (g)	Shock Test	Resonance Frequency (Hz)	Operating Temp Range (℃)
JMZ-T1-0.3	0.3	≤0.6	19.5±0.5	16	M4-7H/ M3-7H	≤58	30g,11ms	＜30	-65～+120
JMZ-T1-0.45	0.45
JMZ-T1-0.6	0.6
JMZ-T1-1.2	1.2		22±0.5	17.5
JMZ-T1-1.4	1.4
JMZ-T1-2.0	2.0

Vibration Curve of JMZ-T1 Series

Impact Curve of JMZ-T1 Series
